What is Monel Alloy 400 Sheet & Plate ?

Monel 400 Sheet & Plate is a copper-nickel base alloy plate. Along with these, it is traced with the amount of manganese, silicon, and carbon content. These alloy 400 plates have good ductility and facilitate superior resistance to a broad range of corrosive circumstances. These plates exhibit outstanding resistance to alkaline and acidic environment. However, it posses great thermal conductivity in annealed conditions. This grade of plates comprises high tensile strength and toughness. Furthermore, these are suitable in subzero temperature from 1000 °F. Thus these plates get good hardness by the cold working process.

The model 400 plates and sheets resist stress corrosion cracking and pitting corrosion. Therefore it shows good resistance to marine conditions. however, these are designed in the cold and hot rolled formed.

As the reputed firm in the market, Yash Internationals provides a wide collection of Monel 400 Sheet & Plate. Therefore we manufacture and supply product to our domestic as well as global clients at cost effective rate.

Standard Specification for Monel 400 Sheet & Plate
Equivalent Grades of Monel 400 Sheet & Plate
Types Of Monel 400 (2.4360) Sheet & Plate
Chemical Composition of Monel 400 Sheet & Plate
Mechanical Properties Monel 400 Sheet & Plate
People Also Searched for
Price of Monel Alloy 400 Sheet & Plate
Makes of Monel 400 Sheet & Plate
Application of ASTM B127 Monel 400 Sheet & Plate

Monel 400 Cold Rolled (CR) Sheet & Plate, ASME SB 127 Monel 400 Sheet, Monel Alloy 400 Hot Rolled (HR) Sheet & Plates, Monel 400 Plates Stockists in Mumbai, Monel 400 Sheet and Plate Supplier in India. ASTM B127 Monel 400 Sheet & Plate Exporter, Monel 400 Circles, Monel Alloy 400 Shim Sheets, Monel 400 Coils, Monel 400 Perforated Sheets Supplier in Mumbai, Monel 400 Export Quality Sheet & Plate Stockists in India.

Our product is manufactured all under the direction of professional experts by acquiring the high quality of raw material. However, this raw material is procured from the leading supplier of the market. We have the qualified professionals and a dedicated working team that ensures to obtain a qualitative product.

We make a global standard product by using innovative and advanced technology. our firm offers an exclusive range do the product in varied shapes, sizes, and specifications as per the constraints and demands made by the patrons.

All the entire work is done in our firm is according to the set industrial norms and standards. Our product is highly demanding and is well appreciated for its great finishing, sturdy construction, dimensional accuracy and durability. These are extensively used in various industrial applications. Apart from these, we provide various reliable services to meet up the satisfaction of the patrons.

Testing details

We ensure various testing and inspection of product at a various level of production. Such a test is done to check the quality and accuracy of the product. These tests are chemical analysis, flattening test, hardness test, mechanical test, micro and macro test, flaring test, pitting resistance test, positive material identifications. Another such test is like IGC test, tensile strength test, and many more.

Documentation & certifications

We supply standard test certificates according to the EN10204/3.1B.These certificates are raw material certificates, third party inspection report and 100% radiography test. Documents such as heat treatment charts, material traceability, guarantee letter, quality assurance plan, NABL approved laboratory test reports, fumigation certificates. All such certificates and documents are provided as per the norms of the customers.

Packaging and remarking details

We take care of the quality of the product while delivering the product. Hence we make sure to facilitate an error and damage free product to our customer so we pack the products in high-quality packaging material. Thus we packed the products in wooden case, pallets, cartons, and boxes. we also ensure packaging as per the specification of the patrons. Furthermore, the products are properly remarked with company logo, size, grade and other details of the product.

Standard Specification

Specification

ASTM B127 / ASME SB127

Length

2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm.

Width

1000mm / 1219mm /1250mm / 1500mm / 2000mm

Thickness

Ranging from 0.3mm to 20mm

Hardness

As per ASME A & NACE MR 175

Finish

Hot rolled plate (HR), Cold rolled sheet (CR)

Destructive and Non-Destructive Testing

Mechanical examining like tensile, Elongation and reduction of area.
Chemical examination
Radiographic Test
Pitting Corrosion Test
Positive material recognition
Eddy Current test
Buckling & Crushing test

Monel 400 Sheet & Plate Processing

Heat rolled
Cold rolled
Cutting
Forming Drilling/ Machining
Grinding
Polishing
Testing

Monel 400 Sheet & Plates Equivalent Grades :

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
Monel 400	2.4360	N04400	NW 4400	NA 13	МНЖМц 28-2,5-1,5	NU-30M	NiCu30Fe

Other Types

N04400 Monel Sheet & Plate Manufacturers	Monel 400 Plates Stockholder
Monel 400 Chequered Sheet & Plate Supplier	Monel 400 Sheet & Plate Exporter in India
ASTM B127 Monel 400 CR Sheet & Plate	Monel 400 Hot Rolled Sheet & Plate
Monel 400 Heavy Duty Sheet & Plate	Alloy 400 Sheet & Plate Stockists
Monel 400 Plates Dealer in India	Monel 400 Sheets Distributor in Mumbai
Monel 400 Sheet & Plates Trader in India	Monel 400 HR Sheet & Plates
High Quality Monel 400 Sheets	Industrial Monel 400 Sheet & Plate

Chemical Composition of Monel Alloy 400 Sheet & Plate

Grade	C	Mn	Si	S	Cu	Fe	Ni
Monel 400	0.30 max	2.00 max	0.50 max	0.024 max	28 – 34	2.50 max	63.00 min

Mechanical Properties of Monel 400 Sheet & Plates

Density<	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.8 g/cm3	1350 °C (2460 °F)	Psi – 80,000 , MPa – 550	Psi – 35,0000 , MPa – 240	40 %

People Searched For

astm b127 alloy 400 plate stockists in mumbai, b127 alloy 400 plate stockholder in india, monel 400 plate chemical composition, monel 400 plates price list, astm b127 sheet manufacturers in mumbai, monel 400 sheets stockholder in mumbai, monel 400 plate equivalent grade, b127 alloy 400 plates dealer in mumbai, monel alloy grade 400 plates, monel 400 sheet specifications, astm b127 sheet suppliers in india, satin plates, astm b127 plates manufacturer in india, astm b127 sheet & plates in india, plastic coated plates, b127 sheet stockists in india, monel 400 plate properties, monel 400 2b sheet & plates, monel 400 plates in india, b127 alloy 400 plate exporters in mumbai, monel 400 2d plates, b127 monel alloy sheet & plate traders in mumbai, monel 400 plate prices, sb127 plate exporter in india, monel 400 sheet & plates equivalent, monel 400 ba no-8 sheet & plate, 400 monel sheet thickness, astm b127 plate supplier in mumbai, astm b127 plates in mumbai.

Price Of Monel 400 Sheet & Plate

Monel 400 Hot Rolled Sheet & Plates Stock
US / Metric Ton (FOB Price) on request
Monel Alloy 400 Sheet & Plate
US / Metric Ton (FOB Price) on request
ASTM B127 Monel 400 CR Sheet & Plate
US / Metric Ton (FOB Price) on request
Monel 400 Export Quality Sheet & Plates
US / Metric Ton (FOB Price) on request
Monel 400 High Tensile Sheet & Plates
US / Ton (FOB Price) on request
Cold Rolled Monel 400 Sheet & Plates
US / Ton (FOB Price) on request
